Netafim Screen Guard 80mm Semi Automatic Check Screen Filters with 1610cm² Filtration Area

Designed for long-lasting efficiency and effortless maintenance, the Netafim ScreenGuard™ 80mm Semi-Automatic Check Screen Filter offers industry-leading filtration performance with a generous 1610 cm² filter area—nearly double that of comparable filters. Built for agricultural, landscape, and in-field irrigation systems, it provides excellent protection against debris and sediment, ensuring uninterrupted water flow and system longevity.

This semi-automatic filter features an integrated check valve and a unique cleaning mechanism that allows for fast, tool-free screen flushing without dismantling the unit or halting water flow. Simply turn the handle to clean the filter—minimizing labour and downtime while maintaining consistent irrigation efficiency.

FEATURES

• Extra-Large Filtration Area (1610 cm²): Increases filtering capacity, extends cleaning intervals, and lowers maintenance costs—ideal for dirty water conditions.
• Semi-Automatic Cleaning System: Effortlessly flushes the filter screen with a single handle turn—no need to open the filter or interrupt irrigation.
• Check Valve Functionality: Prevents backflow and enables fast, efficient backwashing when needed.
• Durable & Non-Corrosive Build: Molded from high-strength engineering-grade plastic for long-term durability in outdoor and corrosive environments.
• Stainless Steel 316 Filter Screen: Precision-molded screen with special weave offers superior filtration and easy cleaning, protecting your irrigation system from clogging.
• Flexible Compatibility: Modular design fits easily into existing setups. Can be retrofitted to Netafim manual ScreenGuard™ filters.
• Micron Flexibility: Available with a range of micron-rated screens to suit a variety of water sources and filtration needs.

SPECIFICATIONS

• Filtration Area: 1610 cm²
• Connection Type: Male BSP
• Max Flow Rate:
  • 2" Model – 25 m³/h
  • 3" Model – 30 m³/h
• Minimum Backwash Pressure: 2 bar
• Max Operating Pressure: 8 bar

APPLICATIONS

• Primary filtration for smallholder farms, wells, and single-use dripline systems
• Primary filtration in landscape irrigation networks
• Secondary filtration after sand separators or media filter systems
• In-field filtration for enhanced system protection at emitter level
