Ebara EVMS 304ss Vertical Multistage Pumps

EBARA’s new EVMS vertical multistage pumps are manufactured to the highest standards of quality, and achieve reliable operating performance by means of strict technical evaluation criteria and control programs that involve the whole manufacturing process. Ebara has rethought  the hydraulic design used in multistage pumps. Utilising the latest in computational fluid dynamics and design, followed by rigorous testing, Ebara has developed  a unique impeller design that offer solutions and value to the customer.

The optimised shape of the Shurricane maintains high efficiencies and very significantly reduces the axial thrust -  meaning that any standard IEC motor can be used and  bearing life is improved

• Impellers: 304 stainless steel
• Intermediate casings: 304 stainless steel
• Outer casing: 304 stainless steel
• Bottom casing: 304 stainless steel
• Top casing: 304 stainless steel
• Shaft: 304 or 329 stainless steel (depending on model)
• Motor Bracket: Cast iron
• Mechanical seal: Silicon Carbide/Carbon/EPDM
• Liner Rings: PPS & 304 SS
• O-Rings: EPDM
