DAB K Series Twin Impeller Centrifugal Cast Iron Pumps Manual

The DAB K Series Twin Impeller centrifugal pumps are engineered for high head applications, offering reliable and consistent pressure for domestic, commercial, and agricultural systems. Built with a durable cast iron body and motor support, these pumps are ideal for installations requiring powerful water transfer from rivers, tanks, or dams, particularly where pressure must be maintained across long pipe runs or height elevations.

This manual model is designed for integration with external pressure switches, controllers, or pressurisation systems. The twin impeller design provides greater pressure output than single impeller models, making it ideal for irrigation, lawn watering, and tank-to-building pressure boosting.

With carbon/ceramic mechanical seals, stainless steel shaft, and either technopolymer or cast iron impellers (model dependent), the pump is built for long service life with minimal maintenance. Its asynchronous, air-cooled motor ensures silent and efficient operation, and includes thermal overload protection on single-phase units.

FEATURES

• Twin impeller design for high head pressure applications
• Manual operation – compatible with external pressure systems
• Cast iron construction for excellent durability and corrosion resistance
• Available with technopolymer or cast iron impellers
• Stainless steel shaft and carbon/ceramic mechanical seal
• Asynchronous TEFC motor with quiet operation
• Built-in thermal overload protection (single-phase)
• Sealed-for-life ball bearings for long operating life
• Suitable for both residential and commercial systems
• 24 Months DAB Manufacturer’s Warranty

APPLICATIONS

• Pressurisation units for tank-fed or reticulated water systems
• Pumping from rivers, tanks, dams, and surface sources
• Sprinkler and irrigation systems requiring strong pressure
• Water supply to elevated storage or pressurised tanks
• Booster systems in rural or large domestic settings

TECHNICAL DATA

• Pump Type: Twin Impeller Centrifugal
• Construction:
• Pump Body: Cast Iron
• Motor Support: Cast Iron
• Impeller: Technopolymer or Cast Iron (depending on model)
• Shaft: Stainless Steel
• Seal: Carbon/Ceramic
• Motor Type: Asynchronous, closed, air-cooled
• Bearings: Oversized, greased-for-life, sealed
• Insulation Class: F
• Protection Rating:
• Motor: IP44
• Terminal Block: IP55
• Single-Phase Units: Built-in thermal overload protection
• Three-Phase Units: External overload protection required
