Netafim Octave Ultrasound Digital Water Meters - NMI-M10 & AS4747 Pattern Approved (50-300mm)

by Netafim
PN: 70240-000102
Original price $2,711.50 - Original price $9,228.45
Original price
$2,711.50
$2,711.50 - $9,228.45
Current price $2,711.50

Netafim Arad Octave Ultrasound Digital Water Meters (NMI-10 & AS4747 Pattern Approved)

Pattern Approved (NMI10 & AS4747 Certified) Octave Ultrasonic Water Meters for the ultimate reliability and accuracy. No moving parts, primary digital display, low head loss & integral pulse output.

DOWNLOAD SPEC SHEET

The Arad Octave™ water meter solution; a revolutionary, precise and ultra-reliable ultrasonic bulk water meter. This meter, having both superior hydraulic performance as well as advanced alert, data and statistical features, makes water management easy. A revolutionary, precise and ultra reliable ultrasonic bulk water meter with no moving parts. With superior hydraulic and batteries that last more than 15 years, the Octave is today’s best choice for bulk meters and a must have for installations requiring pattern approval.

Netafim Octave and WST meters are compliant with the Australian National Measurement Institute's M10 (NMI M10) pattern approval for meters used in water and irrigation.

Purchase 70220-060400 Open Drain Pulse Lead Set Kit For Octave Here

Purchase 70220-060410 Octave Solid Stage Relay (SSR) 2CH Output Here

APPLICATIONS

Ideal for all municipal, agricultural and water distribution applications where precise water metering is vital.

FEATURES

  • Ultrasonic Technology
  • Double beam ultrasonic transducers create unsurpassed accuracy and reliability
  • Analogue & Digital Pulse Outputs
  • Using a simple connection you can connect to ARAD Technology’s Dialog 3G leading AMR system
  • No Moving Parts
  • Means no wear and tear, loss of accuracy and no maintenance
  • Digital Display
  • Large and clear digital display features volume and current flow rates
  • Robust Mechanical Design
  • Vacuum sealed IP68 for long life and high performance
  • Long Battery Life
  • 10 year battery life expectancy is the longest on the market

TECHNICAL SPECIFICATIONS

  • Pattern Approved for Murray Darling Basin
  • AS4747 accredited and NMI pattern approved
  • Excellent long-term stability and reliability
  • Rugged mechanical design - Submersible (IP68)
  • Bi-directional - including bi-directional outputs (digital and analog)
  • Flexible data formats including flow directions, flow rates and volumes
  • AMR and cellular networks ready with alerts and statistic features
  • Multiline LCD Programmable Display (units and outputs resolution)
  • EMI / RFI Protection
  • Octaves Sizes 1.5” - 3” come Pre-Configured to 10L & 100L Pulse
  • Octaves Sizes 4” - 12” come Pre-Configured to 100L & 1000L Pulse

DIGITAL DISPLAY


The vacuum sealed (IP68) digital display is equipped with the following:

  • Forward & reverse flow notification symbol
  • 12 digits accumulation volume
  • Programmable decimal point for high resolution
  • 4 digits for flow rate with automatic floating decimal point
  • Programmable accumulation units available
  • Programmable flow rate units available
  • Alarm display for low battery and fault measuring
  • The digital display is identical for all sizes or models and it can be programmed as ordered by you, the customer.

The transparent LCD digital display glass lens is made of moulded
heat treated 6 mm / 1/4” glass to ensure against scratching and
breakage. The Serial number is permanently stamped in the electronic
digital display for easy identification.
