Puretec PureMix Z6 High Flow Inline Undersink Filter System (10LPM)

Premium 0.1 Micron Ultra Z Filtration for Mains Water – Connects to Any Mixer Tap

The Puretec PureMix Z6 is a high-flow, inline undersink filtration system designed specifically for mains water, delivering cleaner, fresher and safer drinking water straight from your existing kitchen mixer tap. The Z6 uses advanced Ultra Z Filtration Technology, a multi-stage filtration process that removes sediment, chlorine, chloramine, pesticides, chemicals, taste, odour, and harmful cysts and bacteria such as E. coli — all the way down to an ultra-fine 0.1 micron.

Engineered for modern high-flow kitchen mixers, the Z6 delivers up to 9.5 L/min at 420 kPa, making it ideal for homeowners who want superior filtration without restricting water pressure. Its valve-in-head design allows for fast filter changes with minimal mess, and the multifunction control valve (PVM65PH) provides pressure limiting, dual check protection and improved safety for installation in Australian homes. According to the specification sheet, the Z6 can be installed vertically or horizontally, saving valuable under-sink space and making it suitable for compact kitchens.

With a long 60,000 L filter capacity, premium brass components and Puretec’s industry-leading 10-year warranty, the PureMix Z6 is the ultimate plug-and-play filtration upgrade for any home wanting better-tasting water with full protection from contaminants.

FEATURES

• High-flow inline filtration: 9.5 L/min @ 420 kPa
• Ultra Z 3-stage filtration reduces contaminants to 0.1 micron
• Stage 1: Sediment, rust, sand, silt, algae
• Stage 2: Chlorine, chloramine, chemicals, sulphur, pesticides, taste & odour
• Stage 3: Ultra Z membrane protects against bacteria & cysts (E. coli, etc.)
• Connects to any mixer tap — no separate faucet required
• Valve-in-head design reduces spills during filter replacement
• PVM65PH Multifunction Valve provides pressure limiting & dual check valve protection
• Long filter life: 60,000 L capacity
• Can be installed vertically or horizontally
• Premium brass stem adaptors & braided hose included
• Suitable for mains water (not recommended for untreated rainwater)
• Industry-leading 10-year warranty (1 year parts & labour + 9 years parts only)

SPECIFICATIONS

• Model: PureMix Z6
• Micron Rating: 0.1 micron (Ultra Z Technology)
• Flow Rate: 9.5 L/min @ 420 kPa
• Temperature Range: 0–38°C
• Pressure Range: 200–520 kPa*
• Connection Size: ½" BSP (15 mm)
• Cartridge Size: 15"
• Filter Capacity: 60,000 L
• Mounting Orientation: Vertical or Horizontal
• Dimensions:
• Vertical: 500 mm (H) × 215 mm (W)
• Horizontal: 215 mm (H) × 500 mm (W)
• Replacement Cartridge: Z6-R
• Multifunction Valve: PVM65PH (Pressure limiting, dual check, multivalve)

APPLICATIONS

• Kitchen drinking water (mains water)
• Cooking, tea, coffee, baby formula
• Homes wanting high-flow filtration without a separate tap
• Households needing chlorine, chemical & bacteria reduction
• Renovations, upgrades & new kitchen installations

INCLUSIONS

• PureMix Z6 filter system
• Z6-R replacement filter cartridge
• 3/8" white QC tubing
• PVM65PH multifunction control valve (pressure limiting & dual check)
• Extra braided hose & brass nipple (extension kit)
• Brass stem adaptors
• Braided hose
• Mounting bracket & screws
• Valve-in-head assembly
• User guide
