Bianco Summit VMS10-20 Solar AC/DC Solar Vertical Multistage Surface Pump (Max 210LPM/230kPa)
Bianco Summit VMS10-20 Solar AC/DC Solar Vertical Multistage Surface Pump (Max 210LPM/230kPa)
DOWNLOAD PRODUCT BROCHURE |
DOWNLOAD INSTALLATION GUIDE |
The Bianco Summit VMS10-20 Solar Series is an efficient and compact solar-powered vertical multistage pump, designed for off-grid or hybrid-powered water transfer and boosting systems. Delivering a maximum flow rate of 210 litres per minute and a max head of 22.1 metres, this pump is ideal for sustainable water supply in agricultural, industrial, and remote applications.
Engineered to operate on both AC and DC power, the VMS10-20 offers flexibility in solar pumping setups—whether connected directly to solar panels or integrated into grid-tied and hybrid systems. Its in-line configuration simplifies installation, with same-size inlet and outlet ports for easy system integration. The pump’s hydraulic components, including the impellers, shaft, and pump body, are made from 304 stainless steel to ensure corrosion resistance and extended life. A durable graphite and silicon carbide mechanical seal provides added reliability under demanding operating conditions.
Built for efficiency, the VMS10-20 features a totally enclosed, fan-cooled 2-pole IE3 motor with an IP55 rating. The removable coupling design allows for fast motor servicing without dismantling the pipework. It operates in temperatures from -15°C to +120°C and is suitable for pressures up to 34 bar. Water-lubricated bearings ensure quiet, smooth, and low-maintenance operation.
FEATURES
- Solar AC/DC compatible for off-grid or hybrid power applications
- Enhanced energy efficiency and quiet operation
- Compact, in-line design for easy installation
- Premium materials: 304 stainless steel pump body, shaft, and impeller
- Durable graphite/S-IC mechanical seal
- Removable coupling for easy motor servicing
- Operates in temperatures from -15°C to +120°C and pressures up to 34 bar
- IP55-rated, fan-cooled motor with water-lubricated bearings
APPLICATIONS
- Solar-powered water supply
- Off-grid and hybrid pumping systems
- Industrial liquid transfer
- Water treatment
- Irrigation in remote or rural areas
SPECIFICATIONS
Brand | Bianco NXT |
Product Type | Vertical Multi Stage |
Amps | 1.68 / 2.94 |
Flow Range Category | b. 100 - 199 L/min |
Flow Rate (L/min) | 167 |
Hp | 1 |
Kilo Watts | 0.75 |
Max Flow (L/min) | 216 |
Max Head (m) | 23 |
Port Size Outlet | DN40 |
Volts | 415 / 230 |
Max Pressure (bar) | 34 |
Min Temp (degrees celsius) | -15 |
Max Temp (degrees celsius) | 70 |
Water Resistant | IP55 |
