Bianco Summit VMS15-10 Solar AC/DC Solar Vertical Multistage Surface Pump (Max 380LPM/140kPa)
Bianco Summit VMS15-10 Solar AC/DC Solar Vertical Multistage Surface Pump (Max 380LPM/140kPa)
| DOWNLOAD PRODUCT BROCHURE |
| DOWNLOAD INSTALLATION GUIDE |
The Bianco Summit VMS15-10 Solar Series is a robust, high-flow vertical multistage pump designed for solar-powered or hybrid water supply systems. With a maximum flow rate of 380 litres per minute and a max head of 13.5 metres, this pump is ideal for off-grid applications that require consistent water movement at lower pressures—such as large-scale irrigation, remote site supply, or rural water transfer.
Compatible with both AC and DC input, the VMS15-10 offers installation flexibility in standalone solar arrays or hybrid grid-connected systems. The in-line configuration and equal-sized inlet and outlet connections simplify installation, while the 304 stainless steel construction across all hydraulic components ensures long-lasting resistance to corrosion. The graphite and silicon carbide mechanical seal adds further durability and reliability under tough conditions.
With a removable coupling design, servicing the motor is quick and efficient—no need to dismantle the entire pump from the system. The motor itself is a totally enclosed, fan-cooled 2-pole unit with IP55 protection and Class F insulation, engineered to withstand fluid temperatures from -15°C to +120°C and pressures up to 31 bar. The bearings are lubricated by the pumped water, ensuring smooth, low-noise operation with minimal maintenance.
FEATURES
- Solar AC/DC compatible for off-grid or hybrid power applications
- Enhanced energy efficiency and quiet operation
- Compact, in-line design for easy installation
- Premium materials: 304 stainless steel pump body, shaft, and impeller
- Durable graphite/S-IC mechanical seal
- Removable coupling for easy motor servicing
- Operates in temperatures from -15°C to +120°C and pressures up to 34 bar
- IP55-rated, fan-cooled motor with water-lubricated bearings
APPLICATIONS
- Solar-powered water supply
- Off-grid and hybrid pumping systems
- Industrial liquid transfer
- Water treatment
- Irrigation in remote or rural areas
SPECIFICATIONS
| Brand | Bianco NXT |
| Product Type | Vertical Multi Stage |
| Amps | 2.31 / 4.2 |
| Flow Range Category | c. 200 - 299 L/min |
| Flow Rate (L/min) | 250 |
| Hp | 1.5 |
| Kilo Watts | 1.1 |
| Max Flow (L/min) | 385 |
| Max Head (m) | 14 |
| Port Size Outlet | DN50 |
| Volts | 415 / 230 |
| Max Pressure (bar) | 31 |
| Min Temp (degrees celsius) | -15 |
| Max Temp (degrees celsius) | 70 |
| Water Resistant | IP55 |
