Bianco Summit VMS5-190 Solar AC/DC Solar Vertical Multistage Surface Pump (Max 140LPM/1950kPa)

The Bianco Summit VMS5-190 Solar Series is an ultra-high-pressure vertical multistage pump built to meet the toughest demands of solar-powered or hybrid water transfer systems. With a maximum flow rate of 140 litres per minute and an exceptional head of up to 195 metres, this pump is the ultimate solution for applications requiring extreme lift and performance in off-grid or hybrid energy environments.

Designed to run on both AC and DC power, the VMS5-190 is ideal for standalone solar systems or installations that combine solar with mains or generator power. Its horizontal in-line layout with DN32 inlet/outlet flanges allows for easy integration into high-pressure pipework. Constructed entirely from 304 stainless steel—including pump body, shaft, and impellers—this model is engineered for long-term durability and corrosion resistance. The graphite and silicon carbide mechanical seal ensures reliable performance even under elevated system pressures.

Serviceability is simplified by a removable coupling that enables motor replacement without disturbing the plumbing. The IP55-rated, fan-cooled 4.0kW motor is built for high-demand operation, supported by Class F insulation, a motor efficiency of 88.1%, and tolerance for fluid temperatures from -15°C to +120°C. The system can withstand pressures up to 32 bar and is equipped with water-lubricated bearings for quiet, low-maintenance performance.

FEATURES

• Solar AC/DC compatible for off-grid or hybrid power applications
• Enhanced energy efficiency and quiet operation
• Compact, in-line design for easy installation
• Premium materials: 304 stainless steel pump body, shaft, and impeller
• Durable graphite/S-IC mechanical seal
• Removable coupling for easy motor servicing
• Operates in temperatures from -15°C to +120°C and pressures up to 32 bar
• IP55-rated, fan-cooled motor with water-lubricated bearings

APPLICATIONS

• Solar-powered water supply
• Off-grid and hybrid pumping systems
• Industrial liquid transfer
• Water treatment
• Irrigation in remote or rural areas

SPECIFICATIONS
