Rain RN 154 25mm Female BSP DC Solenoid Valve for Residential Irrigation with Flow Control

The Rain RN 154 25mm DC Solenoid Valve is engineered for reliable, efficient water control in residential and light commercial irrigation systems powered by battery-operated controllers. Designed to handle flow rates from 30 to 150 litres per minute, this valve offers robust performance and unmatched installation convenience in both new and existing irrigation setups.

Equipped with a 9 Vdc latching solenoid, the RN 154 operates with low power consumption—ideal for battery-powered systems. It opens and closes via short electrical pulses, conserving battery life while maintaining reliable functionality. Its integrated flow control and manual override feature provide added versatility and operational control.

The patented Rain Manifold System allows for tool-free installation and ultra-fast maintenance. The compact 1" F model—with a body length of only 11.2 cm—makes it easy to retrofit into tight valve boxes and replace other standard valves without modification.

FEATURES

• Designed for battery-powered irrigation systems
• Low-power 9 Vdc latching solenoid for energy efficiency
• Manual opening and integrated flow control
• Compact 11.2 cm body for retrofitting into tight spaces
• Patented Manifold System for quick, tool-free replacement
• High durability with 30% glass-filled nylon body
• Compatible with existing 1” valve fittings from other brands

SPECIFICATIONS

• Thread Options: ¾" M, 1" F, 1" M, 1" MxUN
• Solenoid Type: 9 Vdc latching (pulse signal to open/close)
• Operating Pressure: 1 to 12 bar
• Flow Rate: 30 to 150 L/min
• Operating Temperature: 4°C to 70°C
• Material: Co-moulded diaphragm, PA6 30% GF construction
• Power Supply: Battery controller (not included)

APPLICATIONS

• Battery-powered residential irrigation systems
• Off-grid garden and landscape watering
• Retrofit projects and valve box upgrades
• Systems requiring efficient water delivery with minimal maintenance
