Bianco Summit VMS1 Series 304ss Vertical Multistage Variable Speed Packaged Pump Station with NXT VFD Drive (Max 60LPM)

The Bianco Summit VMS1 Series Variable Speed Packaged Pump Station is a premium, energy-efficient water boosting solution designed for precise pressure control in residential, commercial, and light industrial systems. With a maximum flow rate of 60 litres per minute and a high head capacity, this variable speed station ensures consistent water pressure with optimised energy use.

The Bianco VMS1 vertical multistage pump, constructed with durable 304 stainless steel components, forms the foundation of this packaged pump station. The system is pre-assembled on a galvanized mounting base and features a stainless steel manifold, WaterMarked spring check valve, stainless steel isolation ball valve, a 30-bar pressure gauge, and a 10-bar rated stainless steel pressure tank with an isolating valve.

Control and efficiency are delivered through the Bianco NXT DRIVE Variable Frequency Drive, featuring a full-colour touchscreen, advanced protection settings, and intuitive interface. Paired with a 4–20mA pressure transducer, the system automatically adjusts motor speed to maintain constant pressure while minimising energy consumption. Built-in safeguards include dry run, over/under voltage, sensor fault, and phase failure protection.

Compact, intelligent, and easy to install, the VMS1 Drive Series station is engineered for precision performance, ease of use, and long-term reliability in variable speed pressure systems.

KIT INCLUDES

• VMS Pump
• NXT Drive (Variable Frequency Drive)
• Counter Flange (in DN25 to DN65)
• Fiber Gaskets to suit counter flanges
• Watermarked Spring Check Valve
• Manifold (304 Stainless Steel)
• Pressure Transducer
• 30 Bar Liquid Filled Pressure Gauge
• Galvanised Single/Double/Triple Base
• Ball Valve (304 Stainless Steel)
• Pressure Tank Included in Scope of Supply

FEATURES

• Complete variable speed pressure pump system
• NXT DRIVE with full-colour touchscreen and intuitive setup
• 4–20mA pressure transducer for accurate constant pressure control
• High-efficiency 304 stainless steel pump, shaft, and impellers
• Includes galvanised base, SS manifold, check valve, and isolation valves
• 10-bar stainless steel pressure tank with isolator
• VFD enables soft-start, energy saving, and system protection
• IP55-rated, fan-cooled motor with Class F insulation
• Operates in temperatures from -15°C to +120°C and pressures up to 33 bar

APPLICATIONS

• Variable speed pressure boosting for residential and commercial sites
• Water supply with stable pressure for irrigation systems
• Energy-efficient booster setups for multi-storey buildings
• Water transfer requiring constant pressure delivery
• Compact plant rooms or systems requiring VFD integration

MODELS
