Bianco Summit VMS5-60 Solar AC/DC Solar Vertical Multistage Surface Pump (Max 170LPM/460kPa)

The Bianco Summit VMS5-60 Solar Series is a high-pressure, mid-flow vertical multistage pump built for reliable solar or hybrid-powered water transfer in rural, industrial, or off-grid environments. With a maximum flow rate of 170 litres per minute and an impressive max head of 45.5 metres, this pump delivers exceptional performance where high pressure is essential.

Designed for maximum flexibility, the VMS5-60 operates on both AC and DC power, making it perfect for direct solar operation or integration into hybrid and grid-tied systems. Its compact, horizontal in-line layout allows for easy installation, while the use of 304 stainless steel across the pump body, shaft, and impeller ensures strong resistance to corrosion and wear. A graphite and silicon carbide mechanical seal enhances the system’s durability under demanding conditions.

Maintenance is simplified with a removable coupling that enables fast motor servicing without removing the pump from the pipework. The IP55-rated, fan-cooled 2-pole motor is equipped for tough conditions, with Class F insulation and operating range from -15°C to +120°C and up to 32 bar system pressure. Water-lubricated bearings ensure smooth, quiet, and long-term performance.

FEATURES

• Solar AC/DC compatible for off-grid or hybrid power applications
• Enhanced energy efficiency and quiet operation
• Compact, in-line design for easy installation
• Premium materials: 304 stainless steel pump body, shaft, and impeller
• Durable graphite/S-IC mechanical seal
• Removable coupling for easy motor servicing
• Operates in temperatures from -15°C to +120°C and pressures up to 32 bar
• IP55-rated, fan-cooled motor with water-lubricated bearings

APPLICATIONS

• Solar-powered water supply
• Off-grid and hybrid pumping systems
• Industrial liquid transfer
• Water treatment
• Irrigation in remote or rural areas

SPECIFICATIONS
