Zenit DR Blue 40 Series 240v Heavy Duty Drainage Pumps (Max 210LPM/70kPa)

The Zenit DR Blue 40 Series is a robust, heavy-duty submersible drainage pump designed for the safe and efficient removal of clean and slightly soiled wastewater. Built with durability in mind and certified to IECEx Zone 2 standards, this pump is ideal for hazardous environments such as car parks, workshops, garages, and any areas where explosive gases or vapours may occasionally be present.

Engineered with a corrosion-resistant open-channel impeller, dual mechanical seals, and a reinforced anti-clog strainer, this 240V pump is well-suited for both domestic and commercial applications, including continuous and heavy-duty drainage tasks.

FEATURES

• IECEx Zone 2 Certified – safe for use in hazardous environments with flammable vapours or gases
• Ergonomic Technopolymer Handle – for safe and easy lifting and handling
• Twin O-Ring Cable Gland System – ensures maximum electrical sealing and protection
• Dry Motor with Internal Thermal Protection – includes internal start capacitor for safe continuous operation
• Dual Mechanical Seals – one in silicon carbide (SiC) and one in alumina graphite (AL), plus a V-ring for added protection
• Integrated Oil Sump – extends mechanical seal life and simplifies maintenance
• Anti-Clogging System (ACS) – diffuser plate design facilitates solid ejection
• Durable Polypropylene Intake Strainer – impact-resistant and built for longevity
• Quiet Operation – acoustic pressure levels below 70 dB when submerged
• S1 Continuous Duty – suitable for ongoing operation in wet installations

SPECIFICATIONS

• Power Supply: 240 V, 50 Hz
• Rated Output: 0.3 kW / 0.4 HP
• Max Flow Rate: 210 L/min
• Max Head: 7 m (0.7 bar / 70 kPa)
• Outlet Connection: 1¼" BSPF
• Impeller Type: Open multi-vane impeller
• Free Passage: 7 mm
• Current Draw: 2.3 A
• Insulation Class: F
• Protection Rating: IP68
• Operating Mode: Continuous (S1)
• Max Liquid Temperature: 40°C
• pH Range: 6 to 14
• Max Fluid Density: 1100 kg/m³
• Max Starts per Hour: 30
• Noise Level: <70 dB (submerged)
• Cable: 10 m with Shuko plug
• Dimensions: 255 mm Ø x 295 mm H
• Weight: 11.5 kg
• Certification: IECEx – Ex nA nC IIC T3 Gc
• Warranty: 2 Years (Parts & Labour)

APPLICATIONS

• Drainage of rainwater, seepage water, or strained wastewater
• Suitable for clear or slightly soiled liquids with small solids
• Water removal from underground pits, basins, tanks, and garages
• Ideal for car parks, vehicle workshops, bus depots, and hazardous industrial zones
• Residential heavy-duty drainage and stormwater removal
