Zenit DR BluePRO 200 Series 240v Electric Drainage Pumps (Max 690LPM/170kPa)

The Zenit DR BluePRO 200 Series is a premium high-capacity electric drainage pump designed for continuous operation in demanding professional and domestic environments. With a maximum flow rate of 690 litres per minute and a head of up to 17 metres, this heavy-duty submersible pump delivers superior performance for applications requiring high discharge volume.

Built with IECEx Zone 2 compliance, this pump is safe to use in potentially explosive atmospheres and is ideal for handling clear or slightly soiled wastewater, rainwater, and seepage. Featuring a robust multi-channel open impeller, dual silicon carbide mechanical seals, and corrosion-resistant materials, the BluePRO 200 is made for reliability under pressure.

FEATURES

• IECEx Zone 2 Certified – safe for use in explosive gas or vapour environments
• High-Capacity Pumping – handles up to 690 L/min with a max head of 17 m
• Open Multi-Vane Impeller – efficiently handles solids up to 10 x 30 mm
• Aluminium Lifting Handle – coated for strength and corrosion resistance
• Twin O-Ring Cable Gland System – ensures watertight electrical connection
• 2x Silicon Carbide Mechanical Seals (2SiC) – reliable dual seal system with V-ring barrier
• Oil Bath Chamber – protects seals and simplifies maintenance
• Polypropylene Strainer with Cast Iron Diffuser Plate and Foot – rugged, impact-resistant construction
• Breather Valve – assists in priming after periods of non-use
• Internal Start Capacitor & Thermal Protection – integrated for single-phase operation
• Quiet Operation – less than 70 dB in submerged conditions
• Continuous Duty (S1) – ideal for permanent installations and heavy workloads

SPECIFICATIONS

• Power Supply: 240 V, 50 Hz
• Rated Output: 1.5 kW / 2.0 HP
• Max Flow Rate: 690 L/min
• Max Head: 17 m (1.7 bar / 170 kPa)
• Current Draw: 10.0 A
• Capacitor: Internal
• Outlet Size: 2" BSPF
• Impeller Type: Multi-channel open impeller
• Free Passage: 10 x 30 mm
• Motor Type: Dry motor with thermal protection
• Duty Cycle: Continuous (S1)
• Max Liquid Temperature: 40°C
• pH Range: 6 to 14
• Max Fluid Density: 1100 kg/m³
• Max Starts per Hour: 30
• Noise Level: <70 dB
• Ingress Protection: IP68
• Insulation Class: F
• Cable: 10 m (3G1) with Shuko plug
• Weight: 23 kg
• Certification: IECEx – Ex nA nC IIC T3 Gc
• Warranty: 2 Years (Parts & Labour)

APPLICATIONS

• High-volume water removal from underground tanks, basins, and pits
• Professional and industrial dewatering of clear or strained wastewater
• Water transfer in IECEx Zone 2 hazardous areas, including:
  • Car parks
  • Truck stops
  • Vehicle service bays
  • Bus depots
  • Garages
• Suitable for mining, agricultural, and construction sites
• Rainwater and stormwater harvesting or drainage
