Zenit DR Steel 37 240v Compact Stainless Steel Drainage Pumps with Float Switch (Max 150LPM/140kPa)

The Zenit DR Steel 37 is a compact, high-performance submersible drainage pump designed for the reliable removal of clean and slightly soiled water. Constructed from durable chrome-nickel AISI 304 stainless steel, this pump is ideal for stormwater dewatering, draining flooded rooms, emptying tanks, or transferring water from ponds, pits, and rainwater collection systems.

Powered by a robust 0.37 kW motor with built-in thermal overload protection, the DR Steel 37 delivers a maximum head of 13.6 metres and a maximum flow rate of 150 litres per minute, making it suitable for both residential and light commercial applications. The 10 mm free passage impeller allows it to handle small suspended solids with ease.

Equipped with an integrated float switch for automatic operation and a 10-metre power cable, this IP68-rated pump is built for continuous duty (S1) operation and safe long-term submersion up to 10 metres.

FEATURES

• Corrosion-resistant construction in AISI 304 stainless steel
• Through-motor internal cooling ensures safe operation even when partially submerged
• Dual mechanical seals in food-grade oil chamber for durability
• Additional V-ring seal in direct contact with liquid
• Multi-channel open impeller handles solids up to 10 mm
• Removable strainer allows near-dry suction down to 5 mm from the floor
• Built-in float switch for automatic operation
• Quiet operation (below 70 dB submerged)
• Compact, lightweight design with integrated lifting handle

SPECIFICATIONS

• Rated Voltage: 240 V
• Rated Output: 0.37 kW / 0.5 HP
• Max Flow Rate: 150 L/min
• Max Head: 13.6 m (1.36 bar / 140 kPa)
• Current Draw: 3.1 A
• Capacitor: 8 μF
• Outlet Size: 1¼" BSPF
• Impeller Type: Multi-channel open, AISI 304
• Free Passage: 10 mm
• Motor Type: Asynchronous with built-in thermal protection
• Duty Cycle: Continuous (S1)
• Max Liquid Temperature: 40°C (briefly up to 90°C)
• pH Range: 6 to 14
• Max Immersion Depth: 10 m
• Protection Rating: IP68
• Insulation Class: F
• Cable Length: 10 m with Shuko plug
• Dimensions: 170 mm Ø x 300 mm H
• Net Weight: 6.3 kg
• Warranty: 2 Years (Parts & Labour)

APPLICATIONS

• Stormwater dewatering from pits, cellars, and tanks
• Rainwater harvesting and sump drainage
• Flood relief and emergency drainage
• Emptying water from ponds, fountains, and water features
• Utility use in agriculture, light construction, and residential settings
