Franklin Electric 3AMH Series Multistage Pressure Pump with Controller (Max 60LPM/400kPa)

The Franklin Electric 3AMH Series Multistage Pressure Pump combines proven reliability with robust stainless-steel construction, making it ideal for domestic and light industrial water pressure boosting applications. Designed for efficiency and performance, the MH Series features a compact close-coupled design with superior hydraulic efficiency, providing smooth and consistent water pressure in demanding environments.

Each pump is precision-engineered with high-grade 300 series stainless steel components for maximum durability and corrosion resistance, while the heavy-duty motor shaft and robust bearings ensure long service life. The included controller delivers automatic pressure management, dry run protection, and seamless pump operation for reliable everyday performance in households, irrigation systems, and commercial setups.

APPLICATIONS

• Domestic and industrial water supply systems
• Pressure boosting and water distribution
• Garden irrigation and sprinkler systems
• Rainwater harvesting and washdown units
• Industrial plants and various general installations

FEATURES

• Compact close-coupled design – robust and rust-resistant
• Superior hydraulic efficiency for reduced energy use
• Heavy-duty oversized motor shaft for extended life
• 300 series stainless steel body, impellers, and diffusers
• Easy maintenance and long-lasting ball bearings
• Single-phase models supplied with AU/NZ plug
• Built-in thermal relay for motor protection
• Supplied with automatic controller for seamless pressure operation

SPECIFICATIONS

• Max Flow: 60 LPM
• Max Head: 400 kPa
• Flow Range: up to 14 m³/h at 50 Hz (3, 5, and 9 m³/h models)
• Head Range: up to 10 bar
• Inlet: 1¼" BSP MH (3/5)
• Outlet: 1" BSP MH (3/5)
• Max Working Pressure: 10 bar
• Max Ambient Temperature: 40°C
• Liquid Temperature Range:
  • Single-phase: -15°C to 55°C
  • Three-phase: -15°C to 110°C
• Motor: Asynchronous, TEFC, Class F Insulation, IP55 Protection
• Electrical: Capacitor inside terminal box; single-phase with thermal relay

INCLUDED

• Franklin Electric 3AMH Multistage Stainless Steel Pump
• Pump Controller with Dry-Run & Restart Protection
• Pre-wired AU/NZ Plug (Single-Phase)
• User Manual
