Grundfos Stainless Steel Foot Valve for Dosing Pump Inlet Hose without Low Level (460LPH)

The Grundfos Stainless Steel Foot Valve is designed for demanding, high-flow chemical dosing applications where durability, corrosion resistance, and reliable suction performance are essential. Installed at the lower end of the dosing pump inlet hose, it ensures stable priming, prevents backflow, and protects the pump from suction loss during operation.

Rated for flow rates up to 460 L/h, this foot valve is manufactured from stainless steel EN 1.4571, making it suitable for aggressive chemicals and harsh industrial environments. The integrated non-return valve maintains prime between dosing cycles, while the built-in weight and 0.8 mm strainer keep the valve securely positioned at the bottom of the tank and prevent debris from entering the suction line.

This model is supplied without low-level or empty-tank indication, making it ideal for installations where level monitoring is handled externally or is not required.

FEATURES

• Suitable for dosing pumps up to 460 L/h
• Stainless steel EN 1.4571 construction for excellent corrosion resistance
• Integrated non-return valve to maintain suction prime
• Built-in 0.8 mm strainer for pump protection
• Weighted design for stable positioning at the tank base
• No level indication, suitable for externally monitored systems
• Heavy-duty construction for industrial and chemical applications

SPECIFICATIONS

• Maximum flow rate: 460 L/h
• Level indication: Without
• Material (body): Stainless steel EN 1.4571
• Valve ball: Ceramic (Al₂O₃)
• Gasket: PTFE composite
• Connection type: Rp
• Connection size: 3/4"
• Strainer mesh size: 0.8 mm
• Net weight: 0.8 kg

APPLICATIONS

• High-flow chemical dosing systems
• Industrial process dosing
• Water and wastewater treatment plants
• Cooling water and boiler chemical injection
• Aggressive or corrosive chemical dosing applications
• Dosing systems with external level monitoring
