Puretec Hybrid R2 Dual Stage Whole House UV Water Treatment System (130LPM) with Cartridges

The Puretec Hybrid R2 Dual Stage Whole House UV Water Treatment System is a high-capacity, all-in-one filtration and ultraviolet disinfection solution designed for medium to large homes and applications requiring higher flow rates and longer cartridge life. This system filters sediment, chemicals including chlorine, and significantly improves taste and odour, while also being highly effective in eliminating bacteria and parasites in your water.

Compared to the Hybrid R1, the Hybrid R2 features larger, longer-life filter cartridges, making it ideal for properties with higher water demand or where reduced maintenance intervals are preferred. The dual-stage filtration removes dirt, rust, silt and chlorine before water passes through Puretec’s Radfire™ UV technology, which inactivates up to 99.99% of bacteria, including E. coli, Giardia and Cryptosporidium, using a chemical-free, eco-friendly process

Designed for both mains and rainwater supply, the Hybrid R2 includes a reversible mounting bracket, allowing installation from left to right or right to left to suit site conditions. The system must be installed in a location protected from the weather. For outdoor installations, the Puretec Hybrid G Series is recommended

FEATURES

• Dual stage filtration with integrated ultraviolet disinfection

• Washable sediment pre-filter removes dirt, rust, silt and sludge

• Carbon cartridge reduces chlorine, chemicals, bad taste and odour

• Radfire™ UV technology inactivates up to 99.99% of bacteria and parasites

• High flow capacity suitable for medium to large households

• Longer life filter cartridges compared to Hybrid R1

• Reversible mounting bracket for left-to-right or right-to-left installation

• Smart UV controller with lamp countdown timer and audible/visual alarms

• Stainless steel UV chamber for durability and corrosion resistance

• Plug-and-play installation design

• Suitable for mains water and rainwater supplies

APPLICATIONS

• Medium to large residential homes

• Whole house water treatment

• Mains water supply filtration and disinfection

• Rainwater tank systems

• Properties requiring higher flow rates and longer service intervals

• Homes seeking improved water taste, odour and microbiological safety

SPECIFICATIONS

• Maximum flow rate: 130 L/min (at 16 mJ/cm² UV dose)

• UV lamp power: 46 W

• UV technology: Radfire™ ultraviolet disinfection

• Connection size: 1” BSP (25mm)

• Supply pressure: 300 – 875 kPa

• Water temperature range: 0 – 52°C (must be protected from freezing)

• Installation: Indoor or weather-protected location only

• Mounting: Reversible bracket (left or right flow direction)

• Warranty: 3 years (1 year parts & labour, plus 2 years parts only)

• Certification: WaterMark approved (WMTS103)
