Rain Bird 24VAC Solenoid Coil with Filter for PGA Valves

The Rain Bird 24VAC Solenoid Coil with Filter is a genuine replacement component designed specifically for Rain Bird PGA Series commercial solenoid valves. Built for dependable day-to-day operation, this encapsulated solenoid delivers consistent valve actuation while maintaining low power consumption, making it ideal for both residential and commercial irrigation systems using standard 24-volt AC controllers.

Featuring an integrated 90-mesh (200-micron) filter, the solenoid protects the pilot flow path from dirt and debris, helping to prevent blockages that can lead to valve failure or unreliable operation. The captured plunger and spring design ensures smooth opening and closing while eliminating the risk of losing internal components during servicing. Its sealed construction provides excellent resistance to moisture, corrosion, and harsh valve box conditions.

Easy to install and service, this solenoid coil is the perfect solution for restoring performance to existing PGA valves or keeping critical irrigation zones operating reliably. Whether used for routine maintenance or emergency repairs, it ensures long-lasting, trouble-free valve control.

Features

• Genuine Rain Bird replacement solenoid for PGA Series valves
• 24VAC encapsulated coil for reliable, energy-efficient operation
• Built-in 90-mesh (200-micron) filter for superior debris protection
• Captured plunger and spring prevent part loss during maintenance
• Fully sealed design resists moisture and corrosion
• Quick and simple replacement for existing PGA valve solenoids

Specifications

• Voltage: 24VAC, 50/60Hz
• Inrush Current: 0.41–0.45A (typical)
• Holding Current: Approx. 0.14–0.25A
• Coil Resistance: ~30–39 Ohms (nominal)
• Filter: 90-mesh (200-micron) pilot filter
• Compatibility: Rain Bird PGA Series solenoid valves
• Operating Temperature: Up to 52°C ambient

Applications

• Commercial and residential irrigation systems
• Turf, landscape, and sports field watering
• Replacement solenoid for Rain Bird PGA control valves
